Wide Climate Adaptability
Robust Battery Performance
Strong Climbing and Clearance Capability
Durable All-in-One Body Structure
Flexible Customization
Operates reliably in extreme environments with temperatures ranging from -30 °C to +50 °C; suitable for both alpine and tropical regions; supports altitudes up to 2000 m.
Equipped with CATL battery system rated at 144.97 kWh; features an independent battery cooling system, advanced BMS, and insulation monitoring; meets IP68 protection grade for enhanced safety and durability.
25% gradeability and 385 mm minimum ground clearance (skirt edge) ensure stable operation in complex road conditions; approach and departure angles of 14° and 12° support urban and suburban use.
Uses a full-load-bearing frame with metal body and full-vehicle electrophoresis treatment, enhancing corrosion resistance and overall structural integrity.
Key specifications and configurations can be tailored based on customer requirements, ensuring optimal performance for specific market needs.
| Main Parameters | |
| Dimensions(mm) | 8640×2420×3330 |
| Seats |
68/20-29 |
| G.V.W(kg) |
≥13800 |
| Front/rear Suspension(mm) | 1800/2445 |
| Wheelbase（mm） | 4300 |
| Working condition mileage; | 295 |
| Main Configurations | |
| lithium battery | Battery Power CATL 144.97kw.h |
| Motor |
Rated/Peak power： 120/240kw |
| Drive Type |
Direct drive |
| Vehicle Controller |
Standard |
| Suspension System | Air suspension |
| Front Axle |
Disc brakes,5t |
| Rear Axle | Drum brakes,8.8t |
| Braking System |
Pneumatic dual-circuit braking system |
| ABS | WABCO ABS+ASR |
| Steering Gear |
Front and rear up and down adjustable |
| Tires |
245/70R19.5 |
|
Body Frame And Skin |
Metal body and cover, electrophoresis for the entire bod |
| A/C |
No N/A |
| Heater | Optional |
| Defroster | Standard |
| Passenger Door |
Front single, middle double pneumatic inner swing doors |
| Others |
Front and rear traction hooks |
