This model is dedicated to markets of commuting and tourism transit. The high strength structure and energy-saving technology can realize the requirements of safety and energy efficiency. It has high performance and great adaptation to different road conditions.
Long life cycle| 8-year battery warranty;
Low temperature resistance | Charge and discharge normally in cold climate in North China; adapt to climate in both South China and North China;
Great safety | The electric city bus uses high-strength steel design, and the integral chassis; protection of relevant parts in high-voltage system reaches grade-IP67; it uses permanent magnet synchronous motor to secure safety and efficiency; the high-voltage shielded cable effectively avoids disturbances; the perfect safety control tactics ensure all high-voltage parts can secure vehicle safety;
Premium quality | Relying on R&D and testing resources of Chery Group, it has mature technologies and first-class supplier system.;
Specification
10990×2500×3600
47+1（24-50）
Main Parameters
Dimensions(mm)
Seats
G.V.W(kg)
17900
Front/rear Suspension(mm)
2220/2700
Wheelbase（mm）
2119/1863
Working condition mileage;
485
Main Configurations
lithium battery
Battery Power 281.9 kwh
Motor
JING-JIN ELECTRIC Motor
Motor Controller
JING-JIN ELECTRIC Motor Controller
Vehicle Controller
JING-JIN ELECTRIC
Suspension System
Air suspension
Front Axle
Hande Front Axle/Disc Brake
Rear Axle
Hande Electric Drive Rear Axle/Drum Brake
Service Brake
Double circuit pneumatic brake、Self-adjusting arm
ABS
ABS
Steering System
Hydraulic booster steering machine
Tires
275/70R22.5-18PR
Body Frame
Monocoque
A/C
Roof-mounted A/C Cooling Capacity 28000Kcal/h
Heater
Optional
TV
Optional
Passenger Door
Pneumatic Swing Door
Others
Vehicle Electrophoresis、Reversing monitor、CAN、
